CONDUCTIVE MATERIAL :
Aluminium Barrel : 99.6%
Copper Palm : 99.95%
Final Metal State : Fully Annealed, Including Joint.
Joining Method : Friction Welding, Welding Area More Than
Nominal Conductor Area.
Finish : Natural.
Conductivity :
Aluminium61.8% Iacs (Min)
Copper99.7% Iacs
Aluminium Barrel are chemically
treated to reduce contact resistance and corrosion and are
filled electrically conductive corrosion inhabitant with a
jointing compound and capped.
Note:
1) Combinations of
Bi-Metallic Compression Joints are designed on the basis of
current carrying capacity of individual cables.
2) In case additional combinations are required same may
will be provided against specific request
|
